ABB OVR T2 40-275s C QS
OVR T2 40-275s C QS
General Information
- Extended Product Type:
- OVR T2 40-275s C QS
- Product ID:
- 2CTB815704R2600
- EAN:
- 3660308525352
- Catalog Description:
- OVR T2 40-275s C QS Surge Protective Device
- Long Description:
- OVR T2 40-275s C QS Surge Protective Device
สถานะของสินค้า : สินค้าหมด
00
Technical
- Standards:
- IEC 61643-11 / EN 61643-11
- Product Name:
- Surge Protective Device
- Type of Low Voltage Distribution System:
- TT
TN-C
TN-S
- Suitable For:
- To protect the systems against the transient overvoltage (lightning)
- Rated Voltage (Ur):
- 230 V AC
- Nominal AC Voltage of the System (Uo):
- 230 / 400 V
- Voltage Rating DC:
- 350 V
- Voltage Protection Level ( Up):
- 1.4 kV
(L-N) 1.4 kV
(N-PE) 1.4 kV
(L-PE) 1.4 kV
- Maximum Continuous Operating Voltage (Uc):
- (L-PE) 275 V
(L-L) 275 V
(L-N) 275 V
(N-PE) - V
- Temporary Overvoltage Test Value (UT):
- 337 V
- Rated Service Short-Circuit Breaking Capacity (Ics):
- 100 kA
- Discharge Current:
- Nominal 20 kA
Maximum 4 kA
Nominal (8 / 20 µs) 20 kA
I (max, 8 / 20 µs) 40 kA
- Impulse Current:
- I (imp, 10 / 350 µs) 2 kA
- Short Circuit Withstand Icc:
- 100 kA
- Power Loss:
- 28 mW
- Arrester Class:
- II
- Number of Poles:
- 1
- Number of Protected Poles:
- 1
- Number of Conductors:
- 1
- Transmission Standard:
- Optic
- Version:
- Plug-in
- Mounting Type:
- DIN rail (top hat rail) 35 mm
- Product Type:
- QS
- Options Provided:
- Replacement Cartridge
- Preventive Maintenance Feature:
- Yes
- Status Indicator:
- Yes
- Fuse Size:
- 4 modular spacing
Environmental
- Degree of Protection:
- IP20
- Maximum Operating Altitude Permissible:
- Without Derating 5000
Dimensions
- Width in Number of Modular Spacings:
- 1
- Product Net Width:
- 17.6 mm
- Product Net Height:
- 57 mm
- Product Net Depth / Length:
- 67 mm
- Product Net Weight:
- 0.075 kg
Container Information
- Package Level 1 Units:
- box 1 piece
- Package Level 1 Width:
- 117 mm
- Package Level 1 Height:
- 82 mm
- Package Level 1 Depth / Length:
- 25 mm
- Package Level 1 Gross Weight:
- 0.085 kg
- Package Level 1 EAN:
- 3660308525352
Ordering
- Minimum Order Quantity:
- 1 piece
- Customs Tariff Number:
- 85363090
- Country of Origin:
- Bulgaria (BG)
- Selling Unit of Measure:
- piece
Certificates and Declarations (Document Number)
- CQC Certificate:
- 9AKK107680A1974
- Declaration of Conformity - CE:
- 9AKK107992A0892
- Instructions and Manuals:
- 2CTC432106M1701
Popular Downloads
- Data Sheet, Technical Information:
- No document needed
- Instructions and Manuals:
- 2CTC432106M1701
Classifications
- ETIM 6:
- EC000941 - Surge protection device for power supply systems
- ETIM 7:
- EC000941 - Surge protection device for power supply systems
- ETIM 8:
- EC000941 - Surge protection device for power supply systems
- WEEE Category:
- 5. Small Equipment (No External Dimension More Than 50 cm)
- WEEE B2C / B2B:
- Business To Business
- CN8:
- 85363090
- Object Classification Code:
- 141DCC
